ReliaSoft® BlockSim: Process Flow

Process Flow, an advanced ReliaSoft BlockSim module, models equipment reliability and maintainability while analyzing various system flow types. Simulate process flow, gain deeper insights into performance and optimize system operations with ease.
Request a Trial
Request a Quote
blocksim

Process Flow is an advanced module available in ReliaSoft BlockSim for modeling the reliability and maintainability of equipment and for analyzing multiple flow types within the system. It is an essential model-based application, which can be used for the visual design and optimization of any technical processes such as chemical plants, Oil & Gas facilities, power stations, complex manufacturing operations and biological processes such as water treatment.

Effective solutions and continuous improvements with Process Flow module

usp-icon

With Process Flow you can quickly identify any problems and make decisions to implement essential solutions faster.

usp-icon

Model the most complex systems with multiple and various flows to better and more accurate optimize your production.

usp-icon

Evaluate and identify any event to obtain required information on system limitations.

usp-icon

With Process Flow you are able to improve design and therefore optimize and increase availability of different equipment within the system.

usp-icon

Process Flow offers complete solution for process design changes using simulation approach so that you can choose the best scenario.

usp-icon

Highly intuitive with enhanced graphical interface allows easily to identify problems, make and verify necessary changes.

blocksim

Process Flow combines ease of use with powerful features

While system availability can be captured well using traditional Reliability Block Diagrams (RBD), they are usually limited by the results based on such analysis and, in many cases, are not able to capture multiple flow types. This is due to the fact that those diagrams need to be setup based on reliability rather than the actual physical flow.
Unlike traditional RBDs, Process Flow provides the ability to easily create and simulate various flow models. Both availability and multi-flow type throughput can be modeled to give essential metrics that allow better operational and financial decisions to be made in order to improve processes, increase efficiency, and reduce costs.
