Vibration Analysis

nCode VibeSys is a data processing system that contains a powerful set of predefined tools for performing vibration analysis. In addition to general signal processing, VibeSys contains dedicated analyses for early fault detection in rotating machinery, efficiently analyzing and fine-tuning designs for better sound quality, and characterising the dynamics of a structure.

mockups-design.com

nCode VibeSys Brochure

Explore the advanced features of nCode VibeSys, designed to meet your vibration analysis needs with precision and efficiency. Click on the link below to download the brochure and discover how VibeSys can enhance your vibration testing and analysis projects.

Discover key capabilities that make VibeSys a powerful choice for vibration analysis

usp-icon

Design reliable products that meet sound, comfort, and regulatory requirements.

usp-icon

Work more efficiently with tools for editing, viewing vibration database entries, and comparing vibration specification data.

usp-icon

Use proven analysis methods for signal processing with specialised features for quantifying noise and vibration in rotating machinery.

usp-icon

Create a realistic PSD or swept sine shaker vibration test based on measured data.

usp-icon

Validate or enhance structural FE modelling through interactive displays for characterising modal properties.

usp-icon

Save time and cost with scalable interactive processing of data in a graphical workspace.

nCode VibeSys  screenshot - identify modes of vibration and extract modal parameters - frequency response analysis

Characterising the dynamics of components with ease

Modal Analysis is a specialised product option for VibeSys for characterising the dynamics of a machine or structure in terms of its dynamic properties. It enables engineers to determine modal frequencies, modal damping ratios, and mode shapes at a specific frequency. FE results may be validated by comparing modal frequencies to mode shapes with experiemental tests to achieve high quality results prior to physical testing.

Accelerate tests without exceeding realistic levels

Vibration Profile Design provides the ability to create accelerated shaker tests based on equivalence of fatigue damage or shock. It provides a documented, repeatable process for developing vibration profiles from time histories, PSDs or a mix of both before physical parts are made, saving both time and money in environmental qualification and product validation.

LDS electrodynamics shaker table applying a vibration test spectrum in the frequency domain - fits with nCode Vibration Profile Design product
testimonial image showing how prevalent nCode is in the global automotive industry

White Paper Vibration Basics

Learn how VibeSys helps engineers reduce NVH and improve overall vehicle quality by transforming test data into design decisions early on in the development process.
